NK2L Double Lite
Обновлено в 2016 годуОписание
Due to ingenious technology, Lite-doors are very reliable in tough operating conditions, and with a low maintenance need. Lite doors are also safe; the engine has been fitted with a built-in brake, and the side controls have been fitted with a fall-guard safety clutch. The NK2L Double Lite is a basic model with 2 layers of fabric; the model NK4L Warm Lite is also available, which has been fitted with heat insulation material, and is perfect as an external door of a warm room, as well as between a cold and a warm room.
Файлы для скачивания
| Формат | Файл | Размер | Версия | |
|---|---|---|---|---|
| rfa | nk2l-double-literfa.rfa | 5.6 MB | Revit 2015 |
Типоразмеры (2)
| Наименование | CC | Door fabric color | Inside Frame | Installation | Outside Frame | Type |
|---|---|---|---|---|---|---|
| Installation Within Door Opening Fabric fold-up door NK2L Double Lite | No | Championdoor Fabric Blue | Yes | directly in the opening | No | 1 |
| Installation Inside or Outside Door Opening Fabric fold-up door NK2L Double Lite | Yes | Championdoor Fabric White | No | Door installation outside/inside of the door opening. Door installation frame according to the manufacturer's instructions - is not part of the door delivery. | Yes | 0 |
Технические характеристики
| Общее | |
| Категория | Архитектурные объекты |
| Тип | Ворота |
| Материалы | Ткань, Алюминий |
| Сайт производителя | Перейти |
| Размеры | |
| Высота | 2000 mm |
| Ширина | 1600 mm |
| Длина | 120 mm |
| Вес | 1 g |
| Общие характеристики | |
| Article Number | nk2ldl |
| BIMobject Category | Doors |
| BIMobject QR code url | http://championdoor.bimobject.com/nk2ldl |
| Built-in safety brake | inside the motor |
| Built-in safety fall | arresters in bottom beam mechanism |
